Electric Lifting Hoist
  • Electric Lifting HoistElectric Lifting Hoist
  • Electric Lifting HoistElectric Lifting Hoist
  • Electric Lifting HoistElectric Lifting Hoist
  • Electric Lifting HoistElectric Lifting Hoist
  • Electric Lifting HoistElectric Lifting Hoist

Electric Lifting Hoist

Our Electric Lifting Hoist showcases a compact design, small form factor, lightweight build, user-friendly operation, safety, reliability, and versatile applicability. We invite you to purchase the Electric Lifting Hoist from our store. We ensure prompt responses to all customer inquiries within 24 hours.

Send Inquiry    PDF DownLoad

Product Description



Structural Characteristics: Our Electric Lifting Hoist embodies a compact design, small footprint, lightweight construction, ease of operation, and robust safety features. It boasts versatility, accommodating various applications.

Flexibility: Beyond fixed suspension, this hoist adapts to hand-drawn or electric trolleys. It seamlessly integrates into different structures composed of single beams, double beams, and overhead transportation systems for operational diversity.

Applications: Widely utilized across major factories, warehouses, wind power generation sites, logistics centers, docks, batching facilities, and confined work areas. This hoist efficiently handles lifting, loading, and unloading of goods. Additionally, it aids in lifting heavy objects to facilitate work or repair large machinery.

In warehouse, dock, batching, and confined work environments, this hoist showcases its exceptional quality and performance.



Product Specification

Parameters of 220v to 380v converter electric motor lifting hoist

Model

PDH-A-0.5

PDH-A-1

PDH-A-2

PDH-A-2.5

PDH-A-3

PDH-A-5

Capacity (t)

0.5

1

2

2.5

3

5

Standard lifting height (m)

3

Lifting Speed (m/min)

7.2

5.8

3.0

5.0

5.0

2.6

Lifting Motor

Power (kw)

8

8

14

7

10

5

Volt (V)

380

Frequency (Hz)

50

Chain Turns

1

1

2

1

1

2

Chain specification (mm)

Ø 6.3×19

Ø8×24

Ø8×24

Ø11.2×34

Ø11.2×34

Ø11.2×34

Test load (t)

0.625

1.25

2.5

3.125

3.75

6.25

Net Weight (kw)

41

45

53

108

110

130

Weight added with 1m higher (kg)

1.1

1.4

2.8

2.8

2.8

5.6


Feature And Application


The machine body boasts a construction of high-strength tensile shell or die-cast aluminum, meticulously crafted through a precise thin-wall extrusion molding process. Its advanced structural design ensures compactness, lightweight build, dependable performance, user-friendly operation, and extensive applicability. This hoist excels in lifting heavy objects, facilitating loading and unloading tasks, equipment maintenance, and goods lifting.

It's adaptable for installation on suspended I-beams, curved tracks, jib crane rails, and fixed lifting points.

Featuring an independent gearbox system, it houses a secondary coaxial transmission gear mechanism within a sealed gearbox. The hoist incorporates a long-life oil bath lubrication system for enhanced durability. Employing an electric hoist powder metallurgy clutch, it functions as an overload protection device. Additionally, its brake utilizes a disc-type DC electromagnetic field braking system, providing significant...



Details


Electric motor partial outer cover: Crafted from high-strength aluminum using compression casting techniques, these covers boast solidity and lightweight attributes. They efficiently dissipate heat and maintain continuous operation due to their enclosed structure. Ideal for use in environments like chemical plants and electroplating factories.

Side kind braking: An intricately designed system that ensures hoist safety during power outages and prevents overloading. This brake system acts in tandem with the motor braking, creating a dual brake setup that enhances safety and durability.

Anti phase protector: A safeguard against power-supply wiring errors, preventing movement in the control circuit when such issues arise.

Hooks: Forged and heat-treated to ensure strength and durability.

Chain: Fabricated from FEC80 ultra-strong heat-treated alloy steel, providing robustness and resilience.

Advantages: Suitable for usage in adverse conditions such as rainwater, seawater, chemical exposure, etc., ensuring safety and reliability.

Protection class (hoist and push button): Rated at IP55.

ISO: M5 / FEM: 2AM Insulation grade: F

Power supply: 3-phase, 200-600V, 50Hz


Electric Lifting HoistElectric Lifting Hoist

1. Double brake system, mechanical brake and electromagnetic brake are adopted. The mechanical brake adopts the brake pad system of American Raybestos, one of the three major manufacturers of automobile brakes. Technology is more secure. 10. No noise. The national standard is 80 decibels for noise, while the operating sound of this electric hoist is only 40 decibels.



Characteristics of PDH Electric Lifting Hoist:


Dual Brake System: Integrates a mechanical brake with an electromagnetic brake, employing American Raybestos brake pad technology for enhanced safety.


Built-in Load Limiting Device: Automatically halts hoist operation when the lifted load surpasses the rated capacity, preventing potential hazards from overloading.


Upper and Lower Limit Devices: Automatic power cutoff when the hook reaches its extreme positions, ensuring immediate halting of hoist movement.


Overheating Protection: Equipped with a mechanism that automatically shuts off the motor to prevent burnout if the motor temperature rises excessively due to frequent use.


Premium Electrical Components: Utilizes Siemens electrical appliances with a fixed 5-key handle switch, including directional buttons, an emergency stop, open, and close buttons for immediate power cutoff in emergencies.


Locking Device on Lifting Hook: Prevents accidental slippage of the hook lock for added safety.


High-Quality Chain: Employs imported Japanese FEC chain, known for its safety and security.


Built-in Frequency Converter: Allows for selective loading, eliminating the need for external additions. Provides control over the lifting speed as desired.


Precision Die-Cast Aluminum Body: Vacuum die-cast aluminum alloy construction with a plastic surface spray finish. Offers lightweight, efficient heat dissipation, and an aesthetically pleasing appearance.


Low Noise Emission: Operates at a noise level of only 40 decibels, significantly lower than the national standard of 80 decibels, ensuring a quieter working environment.


Electric Lifting HoistElectric Lifting HoistElectric Lifting Hoist
